All in one Portable Battery Storage With 220Ah Capacity 25.6V Voltage MPPT Battery With Lockable Wheels and Handle Power Station
| Model | ASH-5632WH | |
| Electrical Characteristics | Nominal Voltage | 25.6V |
| Nominal Capacity | 220Ah | |
| Energy | 5632Wh | |
| Cycle Life | >2000Cycle @80%DOD, at 25℃ | |
| Communication Mod | RS485/RS232/CAN | |
| Standard Charge | Charge Voltage | 29.2V |
| Standard Charge Current | 100A | |
| Rapid Charge Current | 150A | |
| Max. Charge Current | 150A | |
| Standard Discharge | Discharge Cut-off Voltage | 20V |
| Standard Discharge Current | 100A | |
| Max. Continuous Discharge Current | 150A | |
| Inverter | AC input | 170-280VAC 50/60Hz |
| AC output | 230VAC 50/60Hz | |
| Rated Power | 3000W | |
| Max.PV Array Power | 3000W | |
| MPPT Operating Voltage | 90-450VDC | |
| MPPT Max Charge Current | 80A | |
| Temperature | Charge Temperature | 0℃ ~ 55℃ |
| Discharge Temperature | -20℃ ~ 65℃ | |
| Mechanical | Diamension(H*W*D) | 610*560*270mm |
| Weight | Approx.93±3kg | |
| Other | Parallel Connection | / |
| Security Function | / | |
